milling head height adjustment by rack and pinion
torquing arbor
adapter set ISO-MK
milling head 90° pivoting
drill chuck
drill sleeves
face milling cutter
operator tools
machine and equipment according to the CE-regulations

technical data
table: 820 x 240 mm
working area: 550 x 200 x 120 mm
taper: MK 4
revs: 50-2.520 (12) r.p.m.
motor: 0,85 / 1,1 kW
drilling capacity: 45/50 mm
end milling capacity: 22 mm
face milling capacity: 80 mm
distance spindle-table: 475 mm
throat depth: 261 mm
quill travel: 120 mm
weight: 300 kg
