| Quantity: | |
|---|---|
Distance between centers: 1000mm
Max Ø of spindle bore: 38mm
Spindle speed range: 70~2000rpm
Max swing Ø over bed: 360mm
Max swing Ø over saddle: 212mm
Travel of cross-slide: 160mm
Travel of top-slide: 68mm
Tailstock Taper: MT3
Power of main motor: 1.5kW 220V / 380V
Dimensions: 1800x900x1500
Weight: 505kg
Standard Machine Accessories
3-jaw chuck
4-jaw chuck
Faceplate
Driveplate
Fixed Steady
Traveling Steady
Worklight
Coolant pump
Foot brake
Adjustable feed stopper
Distance between centers: 1000mm
Max Ø of spindle bore: 38mm
Spindle speed range: 70~2000rpm
Max swing Ø over bed: 360mm
Max swing Ø over saddle: 212mm
Travel of cross-slide: 160mm
Travel of top-slide: 68mm
Tailstock Taper: MT3
Power of main motor: 1.5kW 220V / 380V
Dimensions: 1800x900x1500
Weight: 505kg
Standard Machine Accessories
3-jaw chuck
4-jaw chuck
Faceplate
Driveplate
Fixed Steady
Traveling Steady
Worklight
Coolant pump
Foot brake
Adjustable feed stopper
