CNC Milling Machine Model:XK714
Quantity: -
CNC Milling Machine Model:XK714
MAIN FEATURES
1. Table Size:900x400mm
2. Table Travel(X,Y,Z):650x400x500mm
3. Max. Load of Table:400kgs
Specification unit
XK714
Worktable :
Table size
mm
900×400
T slot
no
3
Centre distance
mm
130
T-Width
mm
18
Max. load of worktable
kg
400
Machining range :
Longitudinal travel
mm
650
Cross travel
mm
400
Vertical travel
mm
500
Spindle nose to table surface
mm
120～620
Spidle axis to column surface
mm
510
Spindle :-
Spindle taper
BT40
SpeedRange
rpm
60～6000
Max.spindle torque
N.M
23.5（Servo/50 frequency conversion）
Spindle motor power
kw
5.5
Feed :
Cuttiing feed X/Y/Z
mm / min
2.5～4000
Rapid feed X/Y/Z
m / min
24
Accuracy
Positioning accuracy
mm
±0.02
Repeat positioning accuracy
mm
±0.01
Others
Overall dimensions(LxWxH)
mm
21020/2150/2290
N/W
KG
3350
STANDARD ACCESSORIES
Spindle unit: BT40 8000rpm (factory set up for 6000rpm)
3 axis plastic coated surface hardened rail
Main protection
Quartz Lamp
Cooling system
Automatic Lubrication unit
Electronic hand wheelOPTIONAL ACCESSORIES
Electromagnetic Doorlock
Automatic spiral chip removal system
Automatic chain type chip removal system
4th axis of CNC control system ( Dividing head or Rotary workingMAIN FEATURES
