Quality Machine Tools
● Powerful, maintenance-free motor
● Centrically tensing vice, quadruple guiding,with individually adjustable jaws
● Cutting is always performed at an optimum position towards the work piece
● Clamping system with 4 levers
● Solid machine substructure with holes to assemble the material stand on both sides
● Removable coolant tank with integrated powerful pump
● High-grade, fracture-proof and movable protective device with rapid opening
● Mechanism provides optimum protection when cutting
● Functional, all-surrounding movable protective device with rapid opening mechanism
● Long handle allows sawing without great effort
● Built-in switch with handle
● Well readable angular scale allows precise sawing
● Head swivel range ±45°
● Rapid adjustment of the mitre
MODEL | CS275 | CS315 | CS350 | |
Head rotation | ±45° | ±45° | ±45° | |
Speeds | 48/96rpm | 19/38rpm | 19/38rpm | |
Max. opening | 110mm | 140mm | 150mm | |
Motor power | 1.4/2.0kw | 0.75/1.5kw | 1.1/1.5kw | |
Coolant pump Motor | 40W | 40W | 40W | |
Saw blade size | Max. diameter | Φ275mm | Φ315mm | Φ350mm |
Bore | Φ40mm | Φ40mm | Φ40mm | |
Pin holes | 2xΦ8xPCD55mm | 2xΦ8xPCD55mm | 2xΦ8xPCD55mm | |
0°Max. cutting capacity | Round | Φ60mm | Φ70mm | Φ120mm |
Square | 60x60mm | 70x70mm | 120x120mm | |
Rectangle | 100x60mm | 130x70mm | 135x110mm | |
45°Max. cutting capacity | Round | Φ60mm | Φ70mm | Φ110mm |
Square | 60x60mm | 70x70mm | 110x110mm | |
Rectangle | 70x60mm | 90x70mm | 110x90mm | |
Packing dimensions(LXWXH) | 940X560X1470mm | 980X630X1530mm | 1000X630X1560mm | |
NW/GW | 175/200Kg | 235/265Kg | 260/290Kg |
