CY6266B
Quantity: UNIVERSAL LATHE CY-6140B CY-6240B, CY-6150B,6250B,6166B,6266B
Lathe Features
★ High rigidity spindle system, with absolute temperature rising no higher than 35℃.
★ The headstock, gear-box, apron and bed-ways are made of high quality cast iron, and are all cast with the resin sand foundry technology. The bed ways are induction-hardened, with hardness around HRC 55.
★ The spindle supported by 3-pointed high-precision bearings and all gears in headstock are precisely grinded, the spindle turns smoothly at high speed.
★ Rapid feed system to improve efficiency. Wide range of feed and pitch are available without changing gears.
★ When rapid feeding is on, the tool slide longitudinal travel handwheel will be automatically disfunctioned.
★ Reliable safety devices such as footbrake and emergency power-off switch are assembled. Adjustable overload protection device is also installed in the feed system.
★ The tool post adopts the structure of ratchet pawl, and can be relocked by turning the lever for just half a lap.
★ Tailstock are equipped with double-locked mechanism, smooth and effortless movement is ensured by the elastic scroll devices underneath.
★ With capacity of swing over bed 660mm, swing in gap 830mm, distance between centers 1000 – 5000mm, this lathe covers wide range of working pieces.
SPECIFICATION CY-6140B CY-6240B CY-6150B CY-6250B CY-6166B CY-6266B Swing over bed 400mm 500mm 660mm Swing over cross slide 220mm 300mm 430mm Swing in gap
630mm
710mm
870mm Width of gap
240mm
240mm
240mm Width of bed 390mm 390mm 390mm Length of work piece (max) 750/1000/1500/2000/3000 750/1000/1500/2000/3000/4000/5000mm 750/1000/1500/2000/3000/4000/5000mm Spindle nose D8 D8 D8 Taper of spindle center 1:20 1:20 1:20 Spindle bore diameter 82MM 82MM 82MM Spindle speed 9-1600rmp 9-1600rmp 9-1600rmp Max. output torque of spindle 1500N.m 1500N.m 1500N.m Range of longitudinal feed 0.028-6.43mm/rev 0.028-6.43mm/rev 0.028-6.43mm/rev Range of transverse feed 0.12-2.73mm/rev 0.12-2.73mm/rev 0.12-2.73mm/rev Lead screw pitch 12mm(metric system) 2TPI (inch system) 12mm(metric system) 2TPI (inch system) 12mm(metric system) 2TPI (inch system) Lead screw diameter 40mm 40mm 40mm Metric threads 0.5-224mm(48 pitches) 0.5-224mm(48 pitches) 0.5-224mm(48 pitches) Inch threads 72-1/8TPI (46 pitches) 72-1/8TPI (46 pitches) 72-1/8TPI (46 pitches) Module threads 0.5-112mm(42 pitches) 0.5-112mm(42 pitches) 0.5-112mm(42 pitches) Diameter pitch threads 56-1/4DP (45 pitches) 56-1/4DP (45 pitches) 56-1/4DP (45 pitches) Cross slide travel(max.) 320mm 320mm 360mm Top slide travel (max.) 145mm 145mm 170mm Section specification of tool post 25x25mm 25x25mm 25x25mm Longitudinal rapid traveling speed 4.5m/min (50HZ) 5.4m/min (60HZ) 4.5m/min (50HZ) 5.4m/min (60HZ) 4.5m/min (50HZ) 5.4m/min (60HZ) Transversal rapid traveling speed 1.9mm/min(50HZ) 2.3m/min(60HZ) 1.9mm/min(50HZ) 2.3m/min(60HZ) 1.9mm/min(50HZ) 2.3m/min(60HZ) Morse taper of tailstock center M5 M5 M5 Max. travel of tailstock quill 150mm 150mm 150mm Tailstock quill diameter 75mm 75mm 75mm Main motor 7.5kw 7.5kw 11kw Rapid travel motor 250w 1360rpm 250w 1360rpm 250w 1360rpm coolant pump motor 90w 25L/min 90w 25L/min 90w 25L/min
High rigidity spindle system, with absolute temperature rising no higher than 35 ℃.
Reliable safety devices such as footbrake and emergency power-off switch are assembled. Adjustable overload protection device is also installed in the feed system.Rapid feed system to improve efficiency. Wide range of feed and pitch are available without changing gears.
The bed way is made of high-quality cast-iron and induction-hardened. Hardness is around HRC 55.
Tailstock are equipped with double-locked mechanism, smooth and effortless movement is realized through the underneath elastic scroll devices.
SPECIFICATION CY-6250B CY-6266B Swing over bed 500mm 660mm Swing over cross slide 300mm 380mm Swing in gap 710mm 830mm Width of gap 240mm Width of bed 390mm Length of work piece (max) 750,1000, 2000,3000mm Spindle nose D8 Taper of spindle center 1:20 Spindle bore diameter 82MM Spindle speed 9-1600rmp Max. output torque of spindle 1470N.m Range of longitudinal feed 0.028-6.43mm/rev Range of transverse feed 0.12-2.73mm/rev Lead screw pitch 12mm(metric system) 2TPI (inch system) Lead screw diameter 40mm Metric threads 1-224mm(48 pitches) Inch threads 72-1/8TPI (48 pitches) Module threads 0.5-112mm(42 pitches) Diameter pitch threads 56-1/4DP (45 pitches) Cross slide travel(max.) 320mm 350mm Top slide travel (max.) 145mm 170mm Longitudinal rapid traveling speed 4.5m/min (50HZ) Transversal rapid traveling speed 1.9mm/min(50HZ) Sleeve diameter 75mm
Standard accessories: Optional accessories:
3-jaw chuck Taper turning attachment
4-jaw chuck Micro stop
steady rest Stop for saddle,
follow rest Stop for cross slide
drive plate Quick change tool post
thread chasing dial DRO
live center
center
foot brake
full set illumination system
full set coolant system
full set wrenches and screw driversUNIVERSAL LATHE CY-6140B CY-6240B, CY-6150B,6250B,6166B,6266B
