| Quantity: | |
|---|---|
| Drill Capacity(mm) | 16 |
| Swing（mm) | 250 |
| Spindle Taper | MT2 |
| Speed No. | 5 |
| Speed range(rpm 50Hz) | 5(500-2500) |
| Spindle travel(mm) | 60 |
| Collumn Diameter(mm) | 59.5 |
| Rack&pinion | yes |
| Max distance from spindle to table | 390 |
| Max distance from spindle to base | 510 |
| Base Size(mm) | 350*215 |
| Table Size(mm) | 195*196 |
| Table tilt | yes -45/45° |
| Motor(w)/S1 | 400 |
| Height(mm) | 850 |
| NW/GW(kg) | 30/33 |
| Packing Size(mm) | 690*430*260 |
| Units Per 20' Container | 400 |
| Drill Capacity(mm) | 16 |
| Swing（mm) | 250 |
| Spindle Taper | MT2 |
| Speed No. | 5 |
| Speed range(rpm 50Hz) | 5(500-2500) |
| Spindle travel(mm) | 60 |
| Collumn Diameter(mm) | 59.5 |
| Rack&pinion | yes |
| Max distance from spindle to table | 390 |
| Max distance from spindle to base | 510 |
| Base Size(mm) | 350*215 |
| Table Size(mm) | 195*196 |
| Table tilt | yes -45/45° |
| Motor(w)/S1 | 400 |
| Height(mm) | 850 |
| NW/GW(kg) | 30/33 |
| Packing Size(mm) | 690*430*260 |
| Units Per 20' Container | 400 |
