Double Column Auto Feed

Quantity:
  • 500HA/ Fully Automatic Column Bandsaw. 500mm Round & Square Capacity, Euro Model,

Fully Automatic Column Bandsaw. 500mm Round & Square Capacity, Euro Model,
Description
This Large Capacity Heavy Duty full featured automatic Column Bandsaw is so feature packed, we dont know where to start! Offering precision auto feed cutting capacity via linear guides, twin hydraulic vice, tungsten guides, NC controller, duarable 41mm blade, variable speed control and built-in coolant system. If you're looking for something in this size range, you'll have a tough time finding a better metal-cutting band saw with these features and at this price anywhere else.
Set and forget! Metalworking production shops should take a good look at this!

Features
❚our  auto series offers you the all-in-one solution
❚auto material feeding and auto beam return.
❚heavy duty capacity capable of processing all types of material including packs at full automatic speed
❚2000mm auto rollerfeed table
❚chip conveyor
❚vice pressure regulator and variable speed blade control system
❚twin hydraulic vice operation standard
❚strong construction design
❚heavy duty motors
❚tungsten carbide blade guides
❚coolant system for increased efficiency
❚auto cut-off switch
❚centralised control panel
❚CE compliant

Technical Data Snap-Shot
❚520mm x 500mm cutting capacity
❚20 ~ 90 variable speed range
❚5650mm x 41mm x 1.3mm blade dimensions
❚500mm x 9 max length one way feeding
❚shipping dimensions - 3200mm x 2100mm x 1900mm
❚power - 415V 4Kw
❚approx weight: 2800kg
