Engineer Series X0 Micro Drill

Product Description

Pillar drill for the model engineer and electronics enthusiast
Accurate, compact machine for drilling up to 6mm diameter
Solidly made and with cast iron base
Stable and free from vibration
2 speed ranges with full electronic control
Digital read-out of quill travel with zeroing facility

A very useful little pillar drill for the model engineer, electronics enthusiast or indeed anyone who has the need for an accurate, compact machine for drilling holes up to 6mm diameter. Unlike many other similar drills, the Axminster Model Engineer Series X0 is solidly made and has a hefty cast iron base, making it stable and free from vibration. Features include a choice of two speed ranges with full electronic control within each speed range, digital read-out of the quill travel with zeroing facility and choice of metric or imperial units, coarse or fine downfeed and a quill locking screw. The cast iron base has two T-slots for holding a vice or compound table and there is an adjustable fence bar which clamps to the table to act as a support for the workpiece.

Specification

Base Size	275 x 165mm
Chuck Cap\Type	6mm keyed
Chuck Travel	40mm
Diameter of Column	30mm
Height	400mm
Max Chuck to Base	195mm
Model	X0
Nett Weight	14kg
Overall L x W x H	275 x 165 x 400mm
Power	150W (230V)
Rating	Model Engineer
Speed Range	Variable 0-3,600, 0-5,000rpm
Spindle Taper	B10
Throat	165mm
