FULL FUNCTION CNC LATHE
Quantity: -
KDCL-25/KDCL-28/KDCL-30
TECHNICAL SPECIFICATIONS:ITEM
KDCL-28
Max.swing over bed
Ø520mm
Max.cutting dia.for disc parts
Ø450mm
Max.cutting dia.for axle parts
Ø250mm
Maxmum turned length for axle parts
500mm
Max.cross travel(X)
250mm
Max.longitudinal travel(Z)
540mm
Spindle bore
Ø65mm
Spindle nose
A2-6
Spindle speed
5000rpm
Rapid feed for axis X
36m/min
Rapid feed for axis Z
36m/min
Number of tool post
12
Outside dia. of cutting tool shank
25mm×25mm
Max.inner dia of cutting tool shank
Ø40mm
Tailstock sleeve dia.
Ø80mm
Tailstock sleeve travel
120mm
Tailstock center type
MT.No.4
Bed structure(slant bed)
45°
Capacity for coolant
120L
Power of main motor
11/15kw
Overall dimensions(L×W×H)
4000×1650×2000
Net weight
3800kg
PRODUCT FEATURES
·Use FANUC control system and servo motors .
·The spindle is supported by NSK series bearing.
·An automatic timely lubrication device supplied for the machine.
·It has a stainless steel inner protection and totally sealed outside protection.
·Different control and parts can be combined according to customers requirement.TECHNICAL SPECIFICATIONS:ITEM
KDCL-28
Max.swing over bed
Ø520mm
Max.cutting dia.for disc parts
Ø450mm
Max.cutting dia.for axle parts
Ø250mm
Maxmum turned length for axle parts
500mm
Max.cross travel(X)
250mm
Max.longitudinal travel(Z)
540mm
Spindle bore
Ø65mm
Spindle nose
A2-6
Spindle speed
5000rpm
Rapid feed for axis X
36m/min
Rapid feed for axis Z
36m/min
Number of tool post
12
Outside dia. of cutting tool shank
25mm×25mm
Max.inner dia of cutting tool shank
Ø40mm
Tailstock sleeve dia.
Ø80mm
Tailstock sleeve travel
120mm
Tailstock center type
MT.No.4
Bed structure(slant bed)
45°
Capacity for coolant
120L
Power of main motor
11/15kw
Overall dimensions(L×W×H)
4000×1650×2000
Net weight
3800kg
PRODUCT FEATURES
·Use FANUC control system and servo motors .
·The spindle is supported by NSK series bearing.
·An automatic timely lubrication device supplied for the machine.
·It has a stainless steel inner protection and totally sealed outside protection.
·Different control and parts can be combined according to customers requirement.
