SM-1129V.Bench Lathe, 750mm Centres, 290mm Swing, 38mm Bore, Variable Speed, 2 Axis Digital Read Out
Quantity: -
SM1127V
Description
If metalworking is a serious hobby or you have a small shop, this is an excellent machine for you.
It is a high quality back gear lathe that can do the job of lathes costing thousands more.
2 axis digital read out and variable speed standard, 750mm centres, 290mm swing over bed & a 38mm
spindle bore this is a well packaged machine!!
Features
❚hardened and ground bedways
❚longitudinal & cross feeds included
❚headstock Single-row tapered roller bearings, 32011/p5 (front), 32010/p5 (rear)
❚quick change tool post standard
❚metric and imperial thread cutting
❚camlock 3 and 4 jaw chucks
❚face plate and centres
❚covered lead screw standard
❚fixed and travelling steadies
❚LED work light
❚2 axis digital read out fitted
❚240 Volt operation
❚CE compliant
Technical Data Snap-Shot
❚290mm swing over bed
❚750mm between centres
❚180mm bed width
❚38mm spindle bore
❚75 ~ 2500 RPM – Variable
❚600mm carriage travel
❚140mm cross slide travel
❚80mm compound slide travel
❚160mm 3 jaw chuck
❚200mm 4 jaw chuck
❚3 MT tailstock taper
❚metric threads - (18) 0.2 ~ 3.5mm
❚imperial threads - (21) 8 ~ 56 T.P.I.
❚faceplate supplied
❚fixed & travelling steadies
❚quick change post with 2 x holders
❚2 axis digital readout
❚machine dimensions - 1450mm x 720mm x 680mm (no stand)
❚crate size - 1500mm x 750mm x 750mm High x 230Kg
❚power - 240V 1.1Kw
❚approx weight: 210kg (excluding stand)
❚optional stand available
EQUIPMENT & ACCESSORIES SUPPLIED
2 axis digital readout - 3 & 4 jaw chuck, quick change tool
post with 2 holders, face plate & centres, fixed steadies &
1 x travelling steady, full length splash guard, drip tray,
covered leadscrew, interlocked chuck guard, headstock cover.Description
