Drilling capacity max. | 40 mm |
Drill chuck | 1 - 16 mm / B 18 |
Morse taper | MT 4 |
Spindle speed, stepless | 90 - 1455 rpm |
Distance spindle to column | 320 mm |
Table tiltable | -50° to +50° |
Distance spindle to table max. | 590 mm |
Distance spindle to base | 1155 mm |
Spindle stroke | 160 mm |
Spindle feed | 0,1 / 0,2 / 0,3 mm/rev. |
Column diameter | 120 mm |
Tabe size / T-slot size | 505 x 425 mm / 14 mm |
Working surface of base | 360 x 370 mm |
Motor power | 1,0 / 1,5 kW |
Machine dimension (W x D x H) | 500 x 930 x 1870 mm |
Weight approx. | 380 kg |
