Quality Machine Tools
Drilling capacity | 30 mm |
Max.tapping capacity | 16 mm |
End mill capacity | 40 mm |
Face mill capacity | 55 mm |
Longitudinal axis (X) | 450 mm |
Cross axis (Y) | 245 mm |
Headstock travel (Z) | 335 mm |
Throat | 290 mm |
Max distance spindle to table | 430 mm |
Spindle taper | MT4 or R8 |
Spindle speed | 100-1600 ±10% rpm |
Table effective size | 240×820mm |
T-slot size | 14mm |
Head tilt | 45°L, 45°R |
Motor output power | 1500 W |
Overal dimension (LxWxH) | 1060x840x1160 mm |
Packing size (LxWxH) | 1240x980x1300 mm |
Weight(Net/Gross) | 310/340 k |
