DESCRIPTION
Professional lathe, dedicated to mechanical workshops that perform extremely precise and large jobs. In fact, the Olympus 2000 Digit lathe is known for its robustness, quality and precision like all Damatomacchine machines. The lathe is equipped with an automatic norton box, a white water cooling pump and a lamp for direct lighting. Having the electronical advancement operated by a Joistick in all directions as well as threading allows countless processes. It is supplied in a standard configuration with two bezels, a 3-jaw external chuck, 2 fixed tailstocks and a set of service keys.
| Technical data | |
| MACHINE DIMENSIONS | |
| Dimensions with basement | 3210 mm (length) x 1230 mm (width) x 1670 mm (height) |
| Size of the package (lathe in cash) | 4400 mm (length) x 1350 mm (width) x 1740 mm (height) |
| Net weight of the machine | 3000.00 kg |
| Gross weight of the package (lathe in cash) | 3400 kg |
| LATHE SPECIFICATIONS | |
| Maximum turning diameter on guides | 560 mm |
| Massimo Turning diameter on the cross sled | 355 mm |
| Maximum workable diameter on the recess | 788 mm |
| Removable recess length | 200 mm |
| Guide Length | 350 mm |
| Distance between centers | 2000 mm |
| Passage bar | 105 mm |
| Mandrino Attack | D1 - 8 |
| Cone Morse passage bar | 7 |
| Max section of tool with turret supplied | 25 x 25 mm |
| Spindle speed numbers | 16 |
| Speed range | 12 speeds 25 ... 1600 rpm |
| Passo Vitemadre | 6 mm |
| Cross travel | 326 mm |
| Longitudinal Turning Advancement | N ° 35 from 0,059 - 1,646 mm |
| Transversal turning advances | N ° 35 from 0.02 - 0.573 |
| Metric threading | No. 47 from 0.2 to 14 mm |
| Threading in inches | N ° 60 from 2 to 112 fil. " |
| DP threading | N ° 50 from 4 to 122 D.P |
| Modular threading | N ° 39 from 0.1 to 7 M.P |
| tailstock | MT5 |
| Tailstock race ride | 180 mm |
| Tailstock shaft diameter | 75 mm |
| Tailstock Racing Tailgate | 235 mm |
| ENGINE | |
| Motor | 7.5 Kw (10 Hp) |
| Pump Motor | 0.09 Kw (1 / 8Hp) |
