X2
Quantity: -
X2
- • With cast iron for vibration free running
- • Milling head and column tilts to 45° Left & Right
- • Variable speed motor with a 2 speed gearbox
- • Coarse down feed for drilling
- • operationsFine down feed control for accurate tool height setting
- • 3MT spindle fitted with a 13mm drill chuck and arbour
Drilling capacity 13 mm End milling capacity 16 mm Face milling capacity 30 mm Longitudinal axis (X) 220 mm Cross axis (Y) 100 mm Headstock travel (Z) 180 mm Throat 167 mm Max. distance spindle to table 280 mm Head tilt 45°L, 45°R Spindle taper MT3 or R8 Motor output power 350 w Spindle speed Low range 100-1100 ±10% rpm High range 100-2500 ±10% rpm Table effective size 390x92 mm T-slot size 12 mm Overal dimension (LxWxH) 520x510x760 mm Package dimension (LxWxH) 540x480x700 mm Weight (Net/Gross) 50/68 kg
