Max.drilling capacity | 20 mm |
Max.tapping capacity | 12 mm |
Max.spindle travers | 80 mm |
Spindle taper | MT2 |
Spindle speed | 100-1500 rpm |
Throat | 250 mm |
Max.distance from spindle nose to worktable | 250 mm |
Max.distance from spindle nost to base surface | 720 mm |
Dimension of worktable face | 320×360 mm |
Diameter of column | 90 mm |
Overall height | 1218 mm |
Motor output power | 1000 W |
T-slot size | 12 mm |
Overal dimension (LxWxH) | 650x425x1220 mm |
Packing size (LxWxH) | 805x570x1395 mm |
Weight(Net/Gross) | 220/260 k |
Max.drilling capacity | 20 mm |
Max.tapping capacity | 12 mm |
Max.spindle travers | 80 mm |
Spindle taper | MT2 |
Spindle speed | 100-1500 rpm |
Throat | 250 mm |
Max.distance from spindle nose to worktable | 250 mm |
Max.distance from spindle nost to base surface | 720 mm |
Dimension of worktable face | 320×360 mm |
Diameter of column | 90 mm |
Overall height | 1218 mm |
Motor output power | 1000 W |
T-slot size | 12 mm |
Overal dimension (LxWxH) | 650x425x1220 mm |
Packing size (LxWxH) | 805x570x1395 mm |
Weight(Net/Gross) | 220/260 k |
