ZN4035A
Quantity: Description: Feature:
Versatile Use in Workshop Applications
High Power at a Low Price
drilling capacity 35 mm
throat 320 mm
spindle nose-to-foot distance 645 mm
spindle speed (12) 125-3030 rpm
spindle mount MT 4
rigid cast-iron construction
height-adjustable machine head
12 speed steps
rectangular table with T-slots and circumferential coolant groove
automatic quill feed
rpm indicator
coolant system
head swivels ± 45°
tapping featureBench-mounted Column Drill Press ZN4035A drilling capacity 35 mm tapping capacity, steel M 22 working area
foot set up area (length x width) 370x360 mm spindle nose-to-foot distance 645 mm throat 320 mm vertical head travel 515 mm column diameter 120 mm headstock
spindle speed (12) 125 - 3030 rpm spindle mount MK 4 / MT 4 quill stroke 155 mm feed
quill feeds (3) 0,1; 0,2; 0,3 mm/R drive capacity
motor rating main drive 1,2 kW measures and weights
overall dimensions 810x500x1670 mm weight 340 kg
