Model | ZWB5035A | ZWB5040A | ZWB5050A |
| | | |
Max. Drilling dia.(steel) and tapping dia.(mm) | φ35/M22 | Φ40/M24 | Φ50/M32 |
| | | |
Max.Travel of spindle(mm) | 190 | 200 | 200 |
| | | |
Max.Distance from spindle to generating line of column(mm) | 340 | 360 | 360 |
| | | |
Max.Distance from spindle nose to surface of worktable.(mm) | 665 | 590 | 590 |
| | | |
Max.Distance from spindle nose to surface of base worktable(mm) | 1195 | 1175 | 1175 |
| | | |
Max Travel of worktable and bracket/Manual(Mechanical)(mm) | 570(450) | 530(410) | 530(410) |
/() | | | |
Swivel angle of worktable | ±45° | ±45° | ±45° |
| | | |
Spindle taper bore | MT4 | MT4 | MT4 |
(MT) | | | |
Spindle speed steps | Stepless | Stepless | Stepless |
| | | |
Spindle speed range(r/min) | 60~3600 | 50~2200 | 50~2200 |
| | | |
Spindle feed steps | 4 | 4 | 6 |
| | | |
Spindle feed range(mm/r) | 0.1;0.2;0.3;0.4 | 0.1;0.2;0.3;0.4 | 0.08~0.50 |
| | | |
Dimension of worktable(mm) | 520×440 | 580×460 | 580×460 |
| | | |
Effective working area of worktable(mm) | 405×395 | 445×435 | 445×435 |
| | | |
Diameter of column(mm) | φ140 | Φ160 | φ180 |
| | | |
Power of motor(kw) | 1.5 | 2.2 | 3 |
| | | |
Machine dimension(mm) | 849×545×2290 | 940×680×2405 | 950×680×2405 |
| | | |
Packing dimension/Net weight and gross weight(mm) | 1000×650×2220 | 1170×680×2300 | 1170×680×2300 |
(kg) | 550/600 | 610/665 | 650/705 |
Sets/20' Container | 20 | 16 | 16 |
