| centre height: | 205 mm |
| turning length: | 1.000 mm |
| spindlebore: | 58 mm |
| revs: | 25 - 2.000 (12) r.p.m. |
| motor: | 5,5 kW |
| bed with: | 300 mm |
| swing over bed: | 410 mm |
| swing over cross slide: | 220 mm |
| swing over dismounted bridge: | 640 mm |
| spindle taper: | MK 6 |
| tail stock taper: | MK 4 |
| metric thread: | 0,1 - 14 (41) mm |
| length: | 2.170 mm |
| width: | 1.130 mm |
| height: | 1.510 mm |
| weight: | 1.670 kg |
equipment
3-axes digital read-out
removeable bridge
3-jaw chuck Ø 250 mm
4-jaw chuck Ø 300 mm
quick change toolpost
steady rest
following rest
face plate Ø 350 mm incl. adapter flange
coolant equipment
halogen working light
foot brake
operator tools
hardened and ground bedways
hardened and ground gear wheels
machine and equipment according to the CE-regulations
