| 钻孔范围：Drill Capacity: | 13mm |
| 夹头：Chuck Capacity: | B16 |
| 立柱直径：Column Diameter: | 48mm |
| 主轴行程：Spindle Travel: | 50mm |
| 旋径：Swing: | 210mm |
| 主轴到工作台最大距离：Max. Distance spindle to table: | 260mm |
| 主轴到底座最大距离：Max. Distance spindle to base: | 340mm |
| 转速范围：Speed Range: | 390～3300RPM (6 speeds) |
| 工作台尺寸：Table Size: | φ170mm |
| 底座尺寸：Base Size: | 330×190mm |
| 机器总高：Height: | 610mm |
| LED灯:LED | NO |
| 十字激光灯：Cross laser: | NO |
| 数显：Digital display: | NO |
| 电机功率：Motor: | 300W(230V 50Hz 4P) |
| 重量：Weight: | 16KG |
| 包装尺寸：Packing Size: | 490×365×250mm |
| 20尺装柜量： Quantity for 20ft | 660PCS |
