| Drilling capacity in steel | 20 mm |
| Drill chuck | 1 - 16 mm / B 18 |
| Morse taper | MT 2 |
| Spindle speed, stepless | 310 - 1950 rpm |
| Distance spindle to column | 180 mm |
| Table tiltable | -45° to +45° |
| Distance spindle to table max. | 690 mm |
| Distance spindle to base | 1170 mm |
| Spindle stroke | 80 mm |
| Column diameter | 72 mm |
| Table size / T-slot size | 305 x 305 mm / 16 mm |
| Working surface of base | 205 x 205 mm |
| Motor power output S1 100% | 0,90 kW / 400 V |
| Motor power input S6 40% | 1,3 kW / 400 V |
| Machine dimension (W x D x H) | 420 x 600 x 1560 mm |
| Weight approx. | 68 kg |
Standard accessories:
| Drilling capacity in steel | 20 mm |
| Drill chuck | 1 - 16 mm / B 18 |
| Morse taper | MT 2 |
| Spindle speed, stepless | 310 - 1950 rpm |
| Distance spindle to column | 180 mm |
| Table tiltable | -45° to +45° |
| Distance spindle to table max. | 690 mm |
| Distance spindle to base | 1170 mm |
| Spindle stroke | 80 mm |
| Column diameter | 72 mm |
| Table size / T-slot size | 305 x 305 mm / 16 mm |
| Working surface of base | 205 x 205 mm |
| Motor power output S1 100% | 0,90 kW / 400 V |
| Motor power input S6 40% | 1,3 kW / 400 V |
| Machine dimension (W x D x H) | 420 x 600 x 1560 mm |
| Weight approx. | 68 kg |
Standard accessories:
