Featuring
The model Z3T-R2B threading machine is equipped with a powerful 750W induction motor which enable the machine process standard threads more quickly.
compact design with cast aluminum body. Easy and fast transport and set-up.
Universal applicable, can also work on workbench.
CE approved
Specifications
Motor: 750W universal type, 115V or 220V, 50-60Hz，Single phase.
Speed: 28 RPM
Capacity: 1/2"-2"
Die head: automatic type for threading
Constant oil flow, through the die head, with an integral oil reservoir
Ordering information
| Code | Model no. | Description | Weight |
| 20005 | Z3T-R2B | complete set.1/2"-2",BSPT 380V-50HZ or 60HZ | 62KG |
Accessories
| Code | Model no. | Description |
| 20200 | 1/2"-2" | Front chuck kit |
| 20220 | 1/2"-2" | Rear chuck kit |
| 20203 | 1/2"-2" | Front chuck jaws 3pcs/set |
| 20300 | 1/2"-2" | Gear box kit |
| 20400 | 1/2"-2" | Die head, automatic |
| 20500 | 1/2"-2" | Reamer kit |
| 20600 | 1/2"-2" | Cutter |
| 20700 | 1/2"-2" | Length change apparatus |
| 20801 | 2" | 380V/50HZ motor |
| 80302 | | Oil pump |
| 80607 | | Cutter wheel |
| 20203 | 2" | Front chuck jaws(3 pcs/set) |
Dies set
| Cat no. | Size | Material |
| 80000 | 1/2"-3/4" BSPT | alloy |
| 80001 | 1"-2" BSPT | alloy |
| 80002 | 1/2"-3/4" NPT (optional) | alloy |
| 80003 | 1"-2" NPT (optional) | alloy |
| 80004 | 1/2"-3/4" BSPT HSS (optional) | HSS |
| 80005 | 1"-2" BSPT HSS (optional) | HSS |
| 80006 | 1/2"-3/4" NPT HSS (optional) | HSS |
| 80007 | 1"-2" NPT HSS (optional) | HSS |
| 80016 | 1/4"-3/8" BSPT(optional) (optional) | alloy |
| 80017 | 1/4"-3/8" NPT(optional) (optional) | alloy |
 |  |
| | |
 |  |
| | |
 |
