Feature:
Feature:
· The box column drilling machines are the heavyweight.
· Lubrication gear head with quite operation
· High torque and drilling capacity
· Table and drill head can be positioned in height
· Rigid constructuion of table and base
· Mechanical spindle auto-feed, tapping function is available
· Widely spindle speeds and feeds provide wonderful machining function
· Main Schneider electrical components provide quality
· Rigid constructuion of base with coolant tank
· Feeding motor for rapid, work feed and back stroke
· Equip with safety spindle guard, LED work lamp, coolant system
| Model No. | Z5163D | Z5180D |
| Drilling capacity | 63mm | 80mm |
| Tapping capacity | M48 | M56 |
| Table capacity | 500kg | 500kg |
| Spindle taper | MT5 | MT6 |
| Spindle speeds | 40~570rpm/9 | 40~570rpm/9 |
| Spindle feed | 0.1~0.78mm/r (6) | 0.1~0.78mm/r (6) |
| Dsitance spindle to column | 375mm | 375mm |
| Dsitance spindle to tabel | 870mm | 810mm |
| Dsitance spindle to base | ~ | ~ |
| Spindle stroke | 250mm | 250mm |
| Drill head travel | 260mm | 260mm |
| Work table travel | 300mm | 300mm |
| Column diameter | ~ | ~ |
| Table size | 650×550mm | 650×550mm |
| T-slot of table | 22mm | 22mm |
| Working surface of base | ~ | ~ |
| T-slot of base | ~ | ~ |
| Net weigh | 2500kg | 2500kg |
| Gross weight | 1750kg | 1750kg |
| Feeding motor (work table) | ~ | ~ |
| Coolant pump | 0.09kw | 0.09kw |
| Main motor | 5.5kw | 5.5kw |
| Dimension of machine | 1450x970x2790mm | 1450x970x2790mm |
| Packing size | 2730×980×1620mm | 2730×980×1620mm |
| Standard accessories | Optional accessories | |
| LED work lamp | Keyless drill chuck | |
| Safety spindle cover | TQ 200 vice | |
| Coolant system | 58pcs clamping kits | |
| Tapping function | ||
| Automatic spindle feed | ||
| Drill chuck | ||
| Arbor | ||
| Tools |
