| Model | CJM320V |
| Max Swing diameter on the bed | 320 mm |
| the distance between center | 500/750mm |
| Max swing over cross slide | 180 mm |
| spindle bore | 38 mm |
| spindle taper | MT.5# |
| Max longitudinal travel over toolpost | 160 mm |
| Max cross slide travel over toolpost | 75 mm |
| Metric thread kinds | 18 |
| Metric thread range | 0.20~3.5 mm |
| Inch thread kinds | 34 |
| Inch thread range | 41/2～48 1/n″ |
| Moudle thread kinds | 16 |
| Moudle thread range | 0.20~1.75 π |
| Pitch thread kinds | 24 |
| Pitch thread range | 16～120 π/DP″ |
| Longitudinal feed range | 0.08~0.56 mm/r |
| Cross-feed range | 0.04~0.28 mm/r |
| Max tailstock quill travel | 60 mm |
| Tailstock quill taper | MT.3# |
| Spindle speed kinds | 3 Kinds+Variable speed in one kind |
| Spidnle speed range | 30~2000 r/mim |
| Main motor | 750W 380V 50HZ (or 220V 50HZ) |
| New weight(without stand) | 300㎏ |
| Gross weight(without stand) | 350㎏ |
Precision ground and hardened bed ways.
The spindle is supported with precision roller bearings.
Headstock gears are made of high quality steel, ground and hardened.
Two different lengths of bed are available.
With or without cabinet according to requirement.
