| Distance between centers | 400mm （can be choose) | 550mm |
| Swing over bed | 250mm | 250mm |
| Width of bed | 135mm | 135mm |
| Spindle bore taper | MT14 | MT14 |
| Spindle bore | 26mm | 26mm |
| Range of spindle speed | 125-2000 rpm/6 | 125-2000 rpm/stepless |
| Range of longitudinal feeds | 0.07-0.20mm/r | 0.07-0.20mm/r |
| Range of inch threads | 8-56tpi | 8-56tpi |
| Range of metric threads | 0.4-3.5mm | 0.4-3.5mm |
| Top slide travel | 70mm | 70mm |
| Cross slide travel | 115mm | 115mm |
| Tailstock quill travel | 70mm | 70mm |
| Tailstock quill taper | MT2 | MT2 |
| Motor power | 850w | 850w |
| Standard Accessories | Optional Accessories |
| • change gears kit | • Faceplate |
| • Dead centres | • Follow/steady rest |
| • Safety spindle cover | • 4-jaw chuck & back plate • Quick change tool rest• Stand• Turning tools |
| • Top rest cover | • Leadscrew cover |
| • tools and tool box | • Treading dial |
