Max. Swing over bed 330 mm
Max. Length of work piece 550 mm
Max. Swing diameter over tool post 220 mm
Spindle Bore 38 mm
Spindle Taper MT.5#
Max Lateral Stroke over tool post 160 mm
Max Longitudinal stroke over tool post 100 mm
Metric Thread kinds on processing 17
Inch Thread kinds on processing 20
Metric thread pitch on processing 0.5-4 mm
Inch thread pitch on processing 9-401 mm
Longitudinal-feed on spindle tool post 0.135 -01.80 mm
Max. stroke of tail stock sleeve 70 mm
Tail stock sleeve taper MT.3#
Spindle speeds available 12
Spindle speeds range 60-1650rpm
Electromotor 1100W/220v/ SOHZ (or110v/60HZ)
Net weight 330kg
Full size 136cm*70cm*56cm
Outer packing size 148 cm * 86 cm * 70 cm
