| TABLE | Table size | 400×145mm |
|
| T slot (amount×width×distance) | 3×12mm×40mm |
|
| Max. load | 20kg |
| TRAVEL | X travel | 260mm |
|
| Y travel | 152mm |
|
| Z travel | 180mm |
|
| Spindle nose to table | 60-240mm |
|
| Spindle center to column | 200mm |
| SPINDLE | Spindle taper | ISO20 |
|
| Spindle motor | 1000w |
|
| Spindle speed | 5000r/min |
| FEED | The max moving speed | 2000mm/min |
|
| The max feeding speed | 500mm/min |
|
| Power of X/Y | 1.35Nm |
|
| Power of Z | 2.2Nm |
| TOOL | Tool number | 4 |
|
| Max.tool diameter | 10mm |
|
| Max.tool length | 110mm |
|
| Max.tool weight | 0.5kg |
|
| Time of tool changing | 10s |
| ACCURACY | Positioning accuracy | 0.015mm |
|
| Repeatability accuracy | 0.01mm |
| OTHERS | Pneumatic supply | 0.6 MPa |
|
| Power | 230V/120V |
|
| Weight（NW/GW） | 280/340kg |
|
| Overall dimension | 1040×860×940mm |
|
| Packing size | 1170×960×1100mm |
