| WORKING AREA | Turning diameter over bed(max) | 200mm |
|
| Travel across slide | 90mm |
|
| Center width | 280mm |
| SPINDLE | Chuck diameter | 100mm |
|
| Spindle speed | 100-3000r/min |
|
| Spindle through-hole | 20mm |
|
| Spindle mount | MT3 |
|
| Spindle motor power | 1000W |
| FEED | X travel | 100mm |
|
| Z travel | 175mm |
|
| The max moving speed | 3000mm/min |
|
| Motor | 3N.m |
| TOOL REST | Tool position | 8 |
|
| Tool dimension 4 internal | ɸ12mm |
|
| 4 external | 8×8mm |
| TAILSTOCK | Tailstock taper | MT1 |
|
| Tailstock sleeve diameter | 22mm |
|
| Travel of tailstock | 30mm |
| ACCURACY | Positioning accuracy | ±0.010mm |
|
| Repeatability accuracy | ±0.005mm |
| OTHERS | Power | 230V/110V |
|
| Weight（NW/GW） | 210/250kg |
|
| Overall dimension | 1070×690×760mm |
|
| Packing Size | 1260×890×1020mm |
