| MODEL | UNIT | GT4270(GH4270) |
| Main Motor Power | Kw | 5.5 |
| Hydraulic Motor Power | Kw | 1.1 |
| Coolant Pump Motor Power | Kw | 0.125 |
| Blade Linear Speed | M/Min | 27/45/69 |
| Blade Feed Type | | Hydraulic Stepless |
| Main Drive Structure | | Gear Speed Reducer |
| Blade Size | Mm | 7205*54*1.6 |
| Machine Dimensions (L*W*H) | Mm | 3500*1800*2500 |
| Blade Tension Type | | Hydraulic |
| Workpiece Feed Type | | Motor Drive |
| Workpiece Clamp Type | | Hydraulic |
| N.W. | Kg | 3500 |
| Cutting Range (Round) | Mm | Φ700 |
| Cutting Range (Rectangular) | Mm | 700*700 |
