| Technical data | |
|---|---|
| Swing over bed | 800 mm |
| Swing over cross slide | 420 mm |
| Swing over gap | 870 mm |
| Turning length over gap | 240 mm |
| Centre distance | 3000 mm |
| Bed | inductively hardened |
| Bed width | 400 mm |
| Lathe chuck diameter | 315 mm |
| Spindle bore | 105 mm |
| Spindle taper | D1-8 CAMLOCK |
| | MT 6 |
| Spindle speeds range | 36 - 1600 rpm |
| Maximal tool dimensions | 25 x 25 mm |
| Feed longitudinal | 0,063 - 2,52 mm/rotation |
| Feed cross | 0,027 - 1,07 mm/rotation |
| Metric thread | 1 - 14 mm |
| Inch thread | 2-28 T.P.I. |
| Modular thread | 0,5-7 mm |
| D.P. thread | 4-56 |
| Rapid feed | longwise-4,5 m/min, cross-1,9 m/min |
| Tailstock spindle diameter | 75 mm |
| Tailstock spindle travel | 150 mm |
| Tailstock spindle taper | MT 5 |
| DIGITAL READOUT | for 3 axes |
| Main motor power | 7,5 kW |
| Flood coolant pump power | 0,09 kW |
| Dimensions | 4600 mm x 975 mm x 1270 mm |
| Net weight | 3800 kg |
