| SWING OVER BED | 1230 mm |
| SWING OVER CROSS SLIDE | 900 mm |
| SWING OVER GAP | 1400 mm |
| CENTRE DISTANCE | 1500 mm |
| SPINDLE TAPER | C11/D11 |
| SPINDLE BORE | 105 mm/130 mm |
| SPINDLE SPEED | 10-800 (18 ranges) |
| SUPPORT PASS | 615 mm |
| UPPER HOLDER PASS | 225 mm |
| QUICK CROSS PASS | Z axis: 3200, X axis: 1400 mm/min |
| SLEEVE DIAMETER | 120 mm |
| SLEEVE BORE | 270 mm |
| SLEEVE TAPER | Morse 6 |
| BED WIDTH | 610 mm |
| METRIC THREADING | 1 - 240 mm |
| INCH THREADING | 30 - 2 tpi |
| MODULAR THREADING | 0.25 - 60 mm |
| DIAMETRAL THREADING | 60-1 tpi |
| LONGITUDINAL FEED | 0.07 - 16.72 mm/rotation |
| CROSS FEED | 0.04 - 9.6 mm/rotation |
| MAIN MOTOR POWER | 11 kW |
| DIMENSIONS | 4340 x 1700 x 2080 mm |
| WEIGHT | 6500-9600 kg |
