FEATURE:
● Widely useful, grind various surfaces
● Spindle and leadscrew is imported
● Mutiple labyrinth seal is used on spindle quill
● Rolling ball guideway is used on longitudinal direction
● Double V type guideways
● Vertical handwheel is fixed on bed
● Manual oil pump lubricates all moveable parts
MAIN PARAMENTERS
| Related presentations |
| MAIN PARAMENTERS | Description |
| M7125 | M7125A | M7125A+ | | Size of worktable(L×W×H) | mm | 500×250×330 | 500×250×330 | 500×250×330 | | Longitudinal table travel | mm | 520 | 550 | 520 | | Cross table travel | mm | 270 | 275 | 275 | | Max.Distance from the spindle centre to the worktable surface | mm | 430 | 410 | 410 | | Safety load of bench(in max) | kg | 100 | 100 | 100 | | Table size | mm | 500×250 | 500×250 | 500×250 | | T-slot | mm×n | 12×1 | 12×1 | 12×1 | | Bench speed | m/min | 3-23 | 3-23 | 3-23 | | Cross auto feed | mm | 0.02/ 3/ | 0.02/ 3/ | 0.02/ 3/ | | Cross rapid feed | mm |
|
| 0.6-10 | | Cross handwheel | mm/min |
| 144 | 144 | | Grinding Wheel size(D×W×d) | mm | 200×16×32 | 200×16×32 | 200×16×32 | | Spindle speed | r/min | 2850 | 2850 | 2850 | | Max.Movement of the vertical mechanism | mm | 430 | 410 | 410 | | Vertical fime adjustment revolution | mm | 1 | 0.15 | 0.15 | | Vertical per fine adjustment graduation | mm | 0.005 | 0.002 | 0.002 | | Spindle motor | Kw | 1.1 | 1.1 | 1.1 | | Overall dimensions:(L×W×H) | mm | 1260×1190×1660 | 1550×1180×1840 | 1550×1180×1840 | | Packing size(L×W×H) | mm | 1300×1220×1950 | 1650×1300×1950 | 1650×1300×1950 | | G/N weight | kg | 1200/1100 | 1600/1400 | 1600/1400 | |
