| Item | Parameter |
| Max. drilling capacity(iron/steel) | 31.5/45mm |
| Max. mill capacity(face/end) | 80/32mm |
| Spindle taper | MT3/MT4/R8/ISO30 |
| Worktable size | 800× 240mm |
| Worktable travelX/Y | 570/230mm |
| Head tilt left right | 90° |
| Spindle travel | 130mm |
| Spindle nose to worktable | 470mm |
| Spindle center to column surface | 285mm |
| Spindle speeds range(2 steps) | 12steps: 75-3200r/min |
| motor | 0.85/1.1kw |
| N. W/G. W | 300/350KG |
| Packing size(L× W× H) | 1140× 960× 2240mm |
| 20’ Container | 12 sets |
| Item | Parameter |
| Max. drilling capacity(iron/steel) | 31.5/45mm |
| Max. mill capacity(face/end) | 80/32mm |
| Spindle taper | MT3/MT4/R8/ISO30 |
| Worktable size | 800× 240mm |
| Worktable travelX/Y | 570/230mm |
| Head tilt left right | 90° |
| Spindle travel | 130mm |
| Spindle nose to worktable | 470mm |
| Spindle center to column surface | 285mm |
| Spindle speeds range(2 steps) | 12steps: 75-3200r/min |
| motor | 0.85/1.1kw |
| N. W/G. W | 300/350KG |
| Packing size(L× W× H) | 1140× 960× 2240mm |
| 20’ Container | 12 sets |
