HEAD:
Variable Head
Bed:
Bed size: 254 x 1270mm
Bed travel: 762mm
Cross travel: 350mm
Knee travel: 405mm
2 x Powerfeed
Spindle:
Spindle taper: R8
Spindle travel: 127mm
Spindle speed: 70~4200rpm
Spindle motor: 3HP
Weight & Dimensions
Dimensions: 1700 x 1700 x 2220 (LxWxH)
Weight: 1168kg
Accessories:
2 axis Xintian DRO
One Shot lubrication
Front + Rearway covers
Drawbar
Tools + Toolbox
Turcite-B coating on x+y slides
P4 Class Spindle bearings
Halogen lamp
Drip Tray
Coolant Pump
Over-arm type control panel
