| Distance between centers (mm) | 2000 |
| Diameter tailstock quill (mm) | 160 |
| Power main motor (Kw) | 22 |
| Net weigth (Kg) | 12000 |
| Diameter of front and rear plate (mm) | 1000 |
| Min. fixation diameter of chuck | 240 |
| Carriage feed (mm/min) | 935 |
| Diametral pitch | 46, 0,5-60 |
| Modular pitch | 46, 0,5-60 |
| Swing over bed (mm) | 1000 |
| Swing over carriage (mm) | 640 |
| Main spindle hole (mm) | 360 |
| Spindle speed range (rpm) | 6,3-315 |
| Metric pitch | 44,1-120 |
| Whitworth pitch per inch | 37, 30-11/8 |
| Max. machining length (mm) | 300 |
| Distance between centers (mm) | 2000 |
| Diameter tailstock quill (mm) | 160 |
| Power main motor (Kw) | 22 |
| Net weigth (Kg) | 12000 |
| Diameter of front and rear plate (mm) | 1000 |
| Min. fixation diameter of chuck | 240 |
| Carriage feed (mm/min) | 935 |
| Diametral pitch | 46, 0,5-60 |
| Modular pitch | 46, 0,5-60 |
| Swing over bed (mm) | 1000 |
| Swing over carriage (mm) | 640 |
| Main spindle hole (mm) | 360 |
| Spindle speed range (rpm) | 6,3-315 |
| Metric pitch | 44,1-120 |
| Whitworth pitch per inch | 37, 30-11/8 |
| Max. machining length (mm) | 300 |
