| | Item | Unit | CE6266E | CE6280E |
| Capacity | Max swing over bed | mm | 660 | 800 |
| Max swing in gap | mm | 870 | 1000 | |
| Effective length in gap | mm | 240 | 240 | |
| Max swing over slide | mm | 420 | 560 | |
| Max workpiece length | mm | 1000/1500/2000/3000 | 2000/3000 | |
| Spindle | Spindle thru-hole | mm | 105 | 105 |
| Spindle nose | | ISO 702/II No.8 cam-lock type | ISO 702/II No.8 cam-lock type | |
| Spindle speed | r/min | 12 step | 12 step | |
| 36-1600 | 30-1400 | |||
| Spindle motor | kW | 7.5 | 7.5 | |
| Tailstock | Quill dia./travel | mm | 75/150 | 90/150 |
| Taper of center | MT | 5 | 5 | |
| Tool post | Number of station/ | | 4 /25X25 | 4/25X25 |
| Tool section | | | ||
| Feed | Max X-axis travel | mm | 145 | 145 |
| Max Z-axis travel | m/min | 310 | 320 | |
| X-axis feed | mm/r | 65 sorts 0.063-2.52 | 65 sorts 0.063-2.52 | |
| Z-axis feed Z-axis feed | mm/r | 65 sorts 0.027-1.07 | 65 sorts 0.027-1.07 | |
| Metric thread | mm | 22 sorts 1-14 | 22 sorts 1-14 | |
| Inch thread | t.p.i | 25 sorts 28-2 | 25 sorts 28-2 | |
| Module thread | TTmm | 18 sorts 0.5-7 | 18 sorts 0.5-7 | |
| DP thread | t.p.i.TT | 24 sorts 56-4 | 24 sorts 56-4 | |
| Others | Coolant pump motor | kW | 0.06 | 0.06 |
| Machine length | mm | 2632/3132/3632/4632 | 3365/4365 | |
| Machine width | mm | 975 | 1340 | |
| Machine height | mm | 1450 | 1490 | |
| Machine weight | kg | 2200/2400/2600/3000 | 3000/3200 |
