Specification | XK7120 |
Max.drilling capacity | 28mm |
Max.end milling capacity | 20mm |
Max.face milling capacity | 63mm |
Table size | 540*180mm |
Spindle taper | MT3/R8 |
Motor power | 1.5KW |
Max. distance form spindle to surface of column | 212mm |
Max. distance form spindle nose to table | 50-330mm |
T-slot size | 12mm |
Table travel (X/Y) | 325*200mm |
Max. spindle travel | 70mm |
Spindle speeds | 50-3000rpm |
Overall size | 1100x900x1530mm |
Packing size | 1200x1100x1750mm |
