| Transmission | Engranes |
| Max. boring capacity (mm) | 50 |
| Feed number and range (mm/min) | 8 (115-1750) |
| Column type | Prismatic |
| Dimensions of the table | 800x240 |
| Table travel (mm) | 300x200 |
| Longitudinal and cross feed | Automático / Variador |
| Headstock rotation | ±90º |
| Max. drilling capacity (mm) (mm) | 25 |
| Weight net/ gross (kg) | 500 |
| Dimensions (mm) (long-width-height) | 1200x1200x1700 |
| Max. distance between the spindle and the table (mm) | 0-400 |
| Distance spindle center/ column (mm) | 320 |
| Spindle travel (drill depth) (mm) | 130 |
| Tapper | CM4 |
| Main motor power (Kw) | 0.85/1.5 |
| Max. reaming capacity | 50 |
| Transmission | Engranes |
| Max. boring capacity (mm) | 50 |
| Feed number and range (mm/min) | 8 (115-1750) |
| Column type | Prismatic |
| Dimensions of the table | 800x240 |
| Table travel (mm) | 300x200 |
| Longitudinal and cross feed | Automático / Variador |
| Headstock rotation | ±90º |
| Max. drilling capacity (mm) (mm) | 25 |
| Weight net/ gross (kg) | 500 |
| Dimensions (mm) (long-width-height) | 1200x1200x1700 |
| Max. distance between the spindle and the table (mm) | 0-400 |
| Distance spindle center/ column (mm) | 320 |
| Spindle travel (drill depth) (mm) | 130 |
| Tapper | CM4 |
| Main motor power (Kw) | 0.85/1.5 |
| Max. reaming capacity | 50 |
