| Drilling capacity in steel | 32 mm |
| Drilling capacity in cast iron | 35 mm |
| Thread cutting max. | M22 |
| Drill chuck | 1 - 13 mm / B 16 |
| Morse taper | MT 3 |
| Spindle speeds / 2 steps | 70 - 495 / 495 - 3500 rpm |
| Feed range | 0,1 / 0,2 / 0,3 mm/rev |
| Distance spindle to column | 280 mm |
| Distance spindle to table max. | 650 mm |
| Distance spindle to base | 1120 mm |
| Spindle stroke | 125 mm |
| Column diameter | 110 mm |
| Table size / T-Slot size | 450 x 380 mm / 14 mm |
| Work surface base | 340 x 330 mm |
| Motor power output S1 100% | 1,1 kW |
| Motor power input S6 40% | 1,5 kW |
| Machine dimensions (W x D x H) | 500 x 800 x 2100 mm |
| Weight approx. | 320 kg |
Standard accessories:
