| SWING OVER BED | 800 mm with LCD readout |
| SWING OVER CROSS SLIDE | 460 mm |
| SWING OVER GAP | 900 mm |
| CENTRE DISTANCE | 3000 mm |
| BED | hartowane indukcyjnie |
| BED WIDTH | 500 mm |
| LATHE CHUCK DIAMETER | 315 mm |
| SPINDLE BORE | 105 mm |
| SPINDLE TAPER | D1-8 DIN 55029 |
| SPINDLE SPEEDS RANGE | 25 - 1600 rpm |
| MAXIMAL TOOL DIMENSIONS | 25 x 25 mm |
| FEED LONGITUDINAL | 0,044 - 1,480 mm/rotation |
| FEED CROSS | 0,022 - 0,740 mm/rotation |
| METRIC THREAD | 0,35 - 120 mm |
| INCH THREAD | 7/16 - 80 Gg/1" |
| TAILSTOCK SPINDLE TRAVEL | 235 mm |
| TAILSTOCK SPINDLE TAPER | MT 5 |
| DIGITAL READOUT | dla 3-osi |
| MAIN MOTOR POWER | 7,5 kW |
| OVERALL DIMENSIONS | 4800 mm x 1320 mm x 1580 mm |
| NET WEIGHT | 3820 kg |
| SWING OVER BED | 800 mm with LCD readout |
| SWING OVER CROSS SLIDE | 460 mm |
| SWING OVER GAP | 900 mm |
| CENTRE DISTANCE | 3000 mm |
| BED | hartowane indukcyjnie |
| BED WIDTH | 500 mm |
| LATHE CHUCK DIAMETER | 315 mm |
| SPINDLE BORE | 105 mm |
| SPINDLE TAPER | D1-8 DIN 55029 |
| SPINDLE SPEEDS RANGE | 25 - 1600 rpm |
| MAXIMAL TOOL DIMENSIONS | 25 x 25 mm |
| FEED LONGITUDINAL | 0,044 - 1,480 mm/rotation |
| FEED CROSS | 0,022 - 0,740 mm/rotation |
| METRIC THREAD | 0,35 - 120 mm |
| INCH THREAD | 7/16 - 80 Gg/1" |
| TAILSTOCK SPINDLE TRAVEL | 235 mm |
| TAILSTOCK SPINDLE TAPER | MT 5 |
| DIGITAL READOUT | dla 3-osi |
| MAIN MOTOR POWER | 7,5 kW |
| OVERALL DIMENSIONS | 4800 mm x 1320 mm x 1580 mm |
| NET WEIGHT | 3820 kg |
