| Ram travel (mm) | 600 |
| Worktable surface (mm) | 1250x320 |
| Cross travel (mm) | 250 |
| Number of ram headstock speeds | 11 |
| Vertical feed (mm/min) | motorizado |
| Distance between the front spindle and the ram slide(mm) | 240 |
| Longitudinal feed (mm/min) | (8) 30-740 |
| Net weight (Kg) | 2000 |
| Longitudinal and cross rapid movement (mm/min) | 1300 |
| Power ram headstock (Kw) | 3 |
| T-slot (mm) | 3x16 |
| Ram travel (mm) | 500 |
| Number of boring speeds | 12 |
| Rapid vertical movement (mm/min) | 600 |
| Distance headstock/ table (mm) | 250-660 |
| Range of speeds (r.p.m) | 40-1300 |
| Ram movement | MANUAL |
| Longitudinal travel (mm) | 985 |
| Cross feed (mm/min) | (8) 30-740 |
| Taper of ram headstock | ISO40 |
| Ram power (Kw) | 3 |
| Max. weight over table (Kg) | 200 |
| Table feed | automático |
| Dimensions (mm) (length - width - high) | 2300x2200x2115 |
| Ram headstock speed range (r.p.m) | 35-1600 |
| Boring taper | ISO40 |
| Traveling (XYZ) | 1000 x 280 x 450 |
| Ram travel (mm) | 600 |
| Worktable surface (mm) | 1250x320 |
| Cross travel (mm) | 250 |
| Number of ram headstock speeds | 11 |
| Vertical feed (mm/min) | motorizado |
| Distance between the front spindle and the ram slide(mm) | 240 |
| Longitudinal feed (mm/min) | (8) 30-740 |
| Net weight (Kg) | 2000 |
| Longitudinal and cross rapid movement (mm/min) | 1300 |
| Power ram headstock (Kw) | 3 |
| T-slot (mm) | 3x16 |
| Ram travel (mm) | 500 |
| Number of boring speeds | 12 |
| Rapid vertical movement (mm/min) | 600 |
| Distance headstock/ table (mm) | 250-660 |
| Range of speeds (r.p.m) | 40-1300 |
| Ram movement | MANUAL |
| Longitudinal travel (mm) | 985 |
| Cross feed (mm/min) | (8) 30-740 |
| Taper of ram headstock | ISO40 |
| Ram power (Kw) | 3 |
| Max. weight over table (Kg) | 200 |
| Table feed | automático |
| Dimensions (mm) (length - width - high) | 2300x2200x2115 |
| Ram headstock speed range (r.p.m) | 35-1600 |
| Boring taper | ISO40 |
| Traveling (XYZ) | 1000 x 280 x 450 |
