3 axes digital read out
feed in all 3 axes
hardended and ground guideways
horizontal milling unit
cooling equipment
machine lamp
torquing arbor
horizontal counter bearing
milling arbor set
adapter set ISO-MK
set of collets
swarf plate
table cover
operator tools
| table: | 750 x 320 mm |
| working area: | 405 x 305 x 400 mm |
| taper: | ISO 40 |
| revs: | 40 - 2000 U/min (18) |
| vertical table: | 830 x 225 mm |
| distance spindle - table: | horizontal spindle 85 - 485 mm, vertical spindle 50 - 450 mm |
| distance vertical spindle-column: | 425 mm |
| max. load on table: | 300 kg |
| feeds (X,Y,Z): | 10-380 mm/min |
| main motor: | 2,2 kW |
| feed motor: | 0,75 kW |
| length: | 1.200 mm |
| width: | 1.400 mm |
| height: | 1.820 mm |
| weight: | 1.300 kg |
