Feature
recycling coolant system
Longitudinal power feed
high-precision spindle
two-speed motor
work light
Technical Parameter
Model | X6350C | X6350Z |
Table size | 280x1120 280x1270 | 280x1120 280x1270 |
Long travel | 600 750 | 600 750 |
Cross travel | 270 | |
Vertical travel | 360 | |
T-slot No. and size | 3x16 5x14 | |
Distance between spindle axis and column surface | 200-600 | 230-630 |
Distance from spindle nose to table surface | 65-425 | 120-480 |
Spindle hole taper | ISO40 / ISO30 / R8 / MT4 | |
Spindle travel | 120 | |
Spindle speed range (50HZ/60HZ) | 115-1750 / 140-2100(V) 40-1300 / 48-1560(H) | 90-2000 / 108-2400(V) 40-1300 / 48-1560(H) |
Spindle motor | 0.85 / 1.5 KW (V) 2.2KW | 2.2KW (V) 2.2KW |
Head swivel | ±45° | |
Dimension of package | 1600x1360x2240 | 1700x1360x2240 |
G.W/set | 1300/1400 | 1350/1450 |
Standard accessories: | |
| 1、Draw bra | 2、Adapter |
| 3、Taper shank for drilling chuck | 4、Drilling chuck |
| 5、T slot bolt | 6、Washer |
| 7、Nut | 8、Tilted wedge |
| 9、Spanner | 10、Oil gun |
| 11、Instruction Manual | 12、Certificate of inspection |
| 13、Pacjing list | |
