| SWING | 1430 mm |
| SWING IN BRIDGE PIECE | 1600 mm |
| SWING OVER CROSS SLIDE | 1100 mm |
| TURNING LENGTH | 1500 mm |
| SPINDLE TAPER | C11 or D11 |
| SPINDLE BORE | 105, 130 mm |
| SPINDLE SPEED | 10 - 800 rpm |
| CROSS TRAVEL | 715 mm |
| REST TRAVEL | 300 mm |
| RAPID TRAVEL (Z/X) | 3200, 1400 mm/min |
| BED WIDTH | 610 mm |
| METRIC THREADS | 1-240/53 mm |
| INCH THREADS | 30 - 2/31 tpi |
| MODULAR THREADS | 0.25 - 60/42 mm |
| DP THREADS | 60-0.5/47 tpi |
| LONGITUDINAL FEED | 0.07-16.72 mm/rotation |
| CROSS-FEED | 0.04-9.6 kW |
| MOTOR POWER | 11 kW |
| DIMENSIONS | 3840 x 1850 x 2220 mm |
| WEIGHT | 9000 kg |
