Max. drilling capacity 40 mm
Threading in steel & last iron 22/24 mm
Distance spindle center to column surface 350 mm
Max. distance spindle nose to worktable 770 mm
Distance spindle nose to base 1215
Spindle taper MT4
Spindle travel 180 mm
Spindle power feed range 0.1mm 0.2mm
Spindle speeds range（option）
L: 80-540 rpm
H: 320-2100rpm
Worktable size 560×560 mm
Dimensions of base 730×510mm
Width of T-slot 18mm
T-slot of base ( Width / Distance / No.) 18mm/200mm /2
Cooling pump 75W
Motor 2.2kW
Overall dimension(L×W×H)mm 2230×560×850m
Packing size(L×W×H)mm 2270×580×1100
N.W/G.W 500/600kg
