HEAD:
Step pulley
BED:
Bed size: 254 x 1370mm
Bed travel: 800mm
Cross travel: 405mm
Knee travel: 405mm
SPINDLE:
Spindle taper: ISO40
Spindle travel: 127mm
Spindle speed: 60~3600rpm
Spindle motor: 3HP
WEIGHT & DIMENSIONS:
Dimensions: 1905 x 1879 x 2235 (LxWxH)
Weight: 1180kg
MACHINE ACCESSORIES:
2 x Powerfeeds
3-axis Sino DRO
Drawbar
Toolbox
Halogen lamp
Coolant Pump
