| SPECIFICATION | UNIT | XZ6350ZB |
| TABLE SIZE | MM | 1120×260 |
| TABLE TRAVEL | MM | 600×270 |
| SPINDLE TAPER | | ISO40 |
| SPINDLE SPEED RANGE | R/MIN | 90-2000(V),38-1310(H) |
| MAX.DRILLING DIA. | MM | 50 |
| AUTOMATIC DRILLING DIA. | MM | 14 |
| MAX.VERTICAL MILLING DIA. | MM | 25 |
| DISTANCE FROM SPINDLE NOSE TO TABLE SURFACE | MM | 100-430 |
| SPINDLE TRAVEL | MM | 120 |
| SPINDLE MOTOR POWER | KW | 2.2 |
| OVERALL DIMENSION(L×W×H) | MM | 1520×1290×2150 |
| NET WEIGHT | KG | 1400 |
