| No. | Specification | Parameter |
| 1 | Table size | 1270mm×320mm |
| 2 | Table travel | 730mm×290mm×380mm |
| 3 | Spindle taper | ISO40 |
| 4 | Max. drilling dia. | 30mm (cast iron) |
| 5 | Automatic drilling dia. | 14mm (Cast iron) |
| 6 | Max. end milling/vertical milling dia. | 125mm/25mm |
| 7 | Distance between vertical spindle nose and table surface | 120--500 |
| 8 | Spindle speed range | 90-2000 (vertical ) 8 steps 60-1350 (horizontal) 12 steps |
| 9 | Spindle travel | 120 |
| 10 | Motor | 2.2kW |
| 11 | Overall size | 1680mm×164mm×2200mm |
| 12 | Net Weight | 1650 kg |
| 13 | Max. tapping dia. | M16 |
| 14 | Automatic spindle feeds | 0.1 0.15 0.3 |
| The specifications are subject to the modifications and improvements without notice. | ||
